Aruba 6100 12-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, Black (JL679A#ABA)* Ethernet Switches & Splitters

Aruba 6100 12-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, Black (JL679A#ABA)* Ethernet Switches & Splitters

$138.89

SKU: SKUIM18DL700 Categories: Computers & Accessories, Ethernet Switches & Splitters, Networking & Wi-Fi Tag: Aruba Brand: Aruba

Description
Reviews (0)

The Aruba CX 6100 Switch Series is a modern family of entry level access switches perfect for branch offices, mid-market enterprise, and SMB networks. Designed for reliable, simple, and secure access, the Aruba CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile, and cloud applications. Prepare your network for tomorrow’s unpredictable demands with a powerful Aruba ASIC architecture and programmable AOS-CX operating system used across the Aruba CX portfolio to deliver a more consistent, more efficient operator experience. This layer 2 switch series has convenient built-in high speed uplinks with up to 139W of IEEE 802.3at Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless 12 port model is perfect for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the Aruba CX 6100 also simplifies ownership with no switch software licensing requirements.

Simplify IT operations with managed Gigabit Ethernet rack mountable switch that provides entry level, reliable, and convenient wired access connectivity
12 10/100/1000BASE-T port model with 2 convenient built-in 1/10 GbE SFP port uplinks and up to 139W of Class 4 PoE
Flexibility to manage and simplify configurations with Aruba Central, Aruba NetEdit, easy to use Web GUI, or industry standard CLI
Throughput: 45.1 Mpps
Dimensions: 1.73″H x 10″W x 10.04″D
Power consumption: 16W idle, 21.9W without PoE, 170W with PoE
Using Aruba AOS-CX operating system across Aruba CX switching platforms and deployment domains provides a simpler, more consistent operator experience
Delivers Layer 2 capabilities with support static routing, ACLs, robust QoS, traffic prioritization, sFlow, and IPv6 support
Simplifies ownership with no switch software licensing or subscriptions required
Designed with Aruba ASICs that deliver very low latency, increased packet buffering, and adaptive power consumption

Specifications table
Attribute name	Attribute value
Data Rate Performances The data transfer rate (DTR) is the amount of data that is moved from one place to another. The greater the bandwidth of a path, the higher the data transfer rate.	10/100/1000 Mbps
Depth in Inches Indicates whether product has gaming capabilities	Non Gaming
Height in Inches The power supply’s voltage, which ultimately powers the device.	100-240 VAC
Jumbo Frame Link Aggregation Control Protocol (LACP) is the practice of bundling individual links on a network to promote better performance outcomes.	Yes
Layer Maximum Data Transfer Rate is the highest rate at which a device can transfer data (in Mbps). For devices with upload and download capabilities, the maximum data transfer rate always refers to download speeds.	1000 – 1499
Network Management Type The number of Ethernet ports on a networking hardware device that Ethernet cables plug into.	12
Performance Class	Yes
Power Supply Power over Ethernet (PoE) is a standard that allows electrical power to pass through Ethernet cables. Devices with built-in PoE do not require any additional power source other than an Ethernet cable.	Yes
Quality of Service Simple Network Management Protocol (SNMP) is an Internet Standard protocol used to monitor and manage the network devices connected over an IP.	v1, v2, v3
Series or Collection	Rack Mountable
True Color	Yes
Warranty Information Weight of the product measured in pounds.	6.13
Width in Inches The overall width of the product, measured left to right.	10
