Aruba Instant On 1930 8-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, White (JL681A#ABA)* Ethernet Switches & Splitters

Aruba Instant On 1930 8-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, White (JL681A#ABA)* Ethernet Switches & Splitters

$124.99

SKU: SKUIM17WA509 Categories: Computers & Accessories, Ethernet Switches & Splitters, Networking & Wi-Fi Tag: Aruba Brand: Aruba

Description
Reviews (0)

The Aruba Instant On 1930 switches features advanced, smart-managed, fixed configuration Gigabit switches designed for small businesses that are easy-to-deploy and affordable. They’re made to handle today’s bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to enhance performance. Using either the Instant On mobile app or the cloud-based web portal, you can quickly set up, monitor and manage the 1930 switch series from anywhere at any time. What’s more, up to 30 W PoE power delivery is available out-of-the-box for your class 4 PoE devices, like access points, surveillance cameras and VoIP phones, all easily managed from the same platform. Built-in security features protect your network from unauthorized access by allowing you to segment traffic and define access to each area of the network. And all of this is included in the price of the hardware – there are no hidden subscription or licensing fees.

Advanced, smart-managed, fixed configuration Gigabit switch is designed for small businesses that are easy-to-deploy and affordable
Contains 8 RJ-45 autosensing 10/100/1000 Class 4 PoE ports and two SFP 1GbE ports
Mobile app allows you to set up, manage, and monitor directly from your phone; built-in security features protect your network from external threats by blocking malware attacks
Supports 14.88 Mpps throughput
Dimensions: 1.73″H x 10″W x 10″D
Maximum power rating: 150.2W; idle power: 11.7W
Certifications and standards: Meets or exceeds UL, IEC, CAN/CSA-C22.2, EN, VCCI-CISPR, FCC standards
Designed to complement the sleek and clean look of the Instant On access points, and to blend discreetly into your site’s environment
Fan-less, making it perfect for quiet office deployments
Two-Factor Authentication (2FA), provides an additional layer of authentication, prevents attackers from remotely accessing the network, and secures sensitive customer information
The cloud-hosted web interface and mobile app make it easy to remotely manage multiple sites, multiple networks, distributed deployments and multi-tenant deployments
For management of individual switches, the intuitive Web GUI makes management simple, even for non-technical users
Enables traffic on a port or VLAN to be simultaneously sent to a network analyzer for monitoring
Allows users to set the locator LED on a specific switch to either turn on, blink, or turn off; simplifies troubleshooting by making it easy to locate a particular switch within a rack of similar switches
Provides time-sensitive packets (like VoIP and video) with priority over other traffic based on DSCP or IEEE 802.1p classification
Delivers data to devices based on the priority and type of traffic; supports IEEE 802.1Q
Provides fiber connections for uplinks and other connections across longer distances than copper cabling can support
SFP ports are in addition to available copper Ethernet ports, providing a higher total number of available ports
Provides up to 30W per port, which allows support of the class 4 PoE
Lifetime manufacturer limited warranty

Specifications table
Attribute name	Attribute value
Number of Ethernet Ports	SFP, SFP+
Weight (lbs.) The data transfer rate (DTR) is the amount of data that is moved from one place to another. The greater the bandwidth of a path, the higher the data transfer rate.	10/100/1000 Mbps
Warranty Information Power over Ethernet (PoE) is a standard that allows electrical power to pass through Ethernet cables. Devices with built-in PoE do not require any additional power source other than an Ethernet cable.	Yes
Network Management Type Indicates whether product has gaming capabilities	Non Gaming
Power Supply Address Database Size is the space the file(s) consume.	8000
Auto-Sensing	Desktop, Rack Mountable
Max. Data Transfer Rate (Mbps)	Yes
Series or Collection An uplink port is a port on a router, or switch, designed to connect a device to another device.	Auto Uplink
Auto-Detecting The overall width of the product, measured left to right.	10
LACP Full-Duplex is a type of communication in which data can be transmitted in both directions on a signal carrier at the same time.	Yes
VLAN Support Output Voltage is the voltage released by a device.	200 – 240
True Color Simple Network Management Protocol (SNMP) is an Internet Standard protocol used to monitor and manage the network devices connected over an IP.	v1, v2, v3
Data Rate Performances	Gigabit Ethernet
Protocols The overall depth of the product, measured front to back.	10
Height in Inches The power supply’s voltage, which ultimately powers the device.	100 – 127
Quality of Service	9216 Bytes
